Description

Key Features

• Good Sleep
• HD Filter
• Dehumidification

Reduces energy use

Energy Saving

Save money every day with digital inverter technology. It maintains the desired temperature without frequently turning off and on, so there’s less fluctuation. And it uses strong magnets and a Muffler, so it is quieter, lasts much longer and reduces energy consumption.

Cools you faster

Fast Cooling

Cool a whole room rapidly and effectively. Fast Cooling mode operates with the fastest fan speed, before slowing down. So it cools or heats much faster compared to the normal mode* and reaches the desired temperature in the shortest time. It’s ideal for immediate relief from the heat outside.

Breathe purer air

HD Filter

Make sure that the air you breathe is always clean and fresh. The HD Filter is really effective at capturing dust, airborne contaminants and allergens, such as pollen, mold spores and pet dander. And it’s also washable, so all you need to do is give it a quick rinse in water and then reuse it.

Enjoy a good sleep

Good Sleep

Enjoy a great night’s sleep – every night! Good Sleep mode automatically controls and fine-tunes the temperature to create the ideal conditions for each stage of the sleep cycle. So you gain precious minutes of sleep and feel fully refreshed. And it also uses less energy than normal cooling.

Cools every corner

2-Way Auto Swing

Create a comfortable environment with an even temperature in every corner. The 2-Way Auto Swing function automatically controls the air flow direction, so it’s quickly and evenly distributed across the room. It can expel cool or warm air further and in every direction to ensure maximum comfort.

Long-lasting cooling

DuraFin+

Stay comfortably cool for much longer. The DuraFin+ is made of corrosion-resistant material to protect the condenser from rusting, which helps to maintain the optimal performance of the Heat Exchanger. Its superb corrosion-resistance was proven using the Salt Spray Test (SST) for 480 hours*.

Specification

Capacity

• Capacity (Cooling, Btu/hr): 17000 Btu/hr
• Capacity (Cooling, Min – Max, Btu/hr): 2,559-18,084 Btu/hr
• Capacity (Cooling, kW): 4.98 kW
• Capacity (Cooling, Min – Max, kW): 0.75-5.30 kW

Energy Efficiency

• EER (Cooling, W/W): 3.00 W/W
• EER (Cooling, Btu/hW): 10.24 Btu/hW

Noise Level

• Noise Level (Indoor, High/Low, dBA): 44/36 dBA
• Noise Level (Outdoor, High/Low, dBA): 53.5 dBA

Electrical Data

• Power Source(Φ/V/Hz): 1 / 220-240 / 50
• Power Consumption(Cooling, W): 1660 W
• Operating Current(Cooling, A): 7.2 A

Physical specification

• Gross Dimension (Indoor, WxHxD, ㎜*㎜*㎜): 1041×320×383 mm
• Gross Dimension (Outdoor, WxHxD, ㎜*㎜*㎜): 872×620×398 mm
• Net Dimension (Indoor, WxHxD, ㎜*㎜*㎜): 970×300×224 mm
• Net Dimension (Outdoor, WxHxD, ㎜*㎜*㎜): 802×555×350 mm
• Gross Weight (Indoor, kg): 17.5 kg
• Gross Weight (Outdoor, kg): 33.0 kg
• Net Weight (Indoor, kg): 13.5 kg
• Net Weight (Outdoor, kg): 27.5 kg
• Loading Quantity (20/40/40Hft with Pipe): 79/163/196

Technical Information

• Piping Length (Max, m): 25 m
• Piping Height (Max, m): 10 m
• SVC Valve (Liquid (ODxL)): φ6
• SVC Valve (Gas (ODxL)): φ12
• Moisture Removal (l/hr): 1.80 l/hr
• Air Circulation (Cooling, ㎥/min): 850 ㎥/min
• Refrigerant (Type): R410A
• Refrigerant (Charging, kg): 0.95 kg
• Low Ambient (Cooling, ℃): 18~48 ℃

Air Flow

• Air Direction Control (Up/Down): Auto
• Air Direction Control (Left/Right): Manual
• Air Flow Control Step (Cool/Fan): 3 Step

Air Purification

• Auto Clean (Self Cleaning): No

Convenience

• Filter Cleaning Indicatior: No
• Indoor Temp. Display: Yes
• Display On/Off: Yes
• Beep On/Off: No
• 24-Hour Timer: Yes
• Auto Changeover: No
• Auto Restart: Yes

Operating Mode

• Fast Cool: Yes
• Good Sleep: Yes
• Dehumidification: Yes
• Fan Mode: Yes
• Quiet: No
